Formfaktor Mini-PC
CPU Intel Core Ultra 7 155H, 6P+8E+2LPE/22T, 1.40-4.80GHz, 24MiB+18MiB Cache, 28-115W TDP (PBP/MTP), Codename "Meteor Lake-H" (Redwood Cove + Crestmont + Crestmont, Intel 4)
Sockel Intel 2049 (BGA2049) [verlötet]
NPU 11 TOPS (Intel NPU 3)
Fernwartung Intel vPro Essentials (SoC+LAN-Controller)
RAM 2x DDR5 SO-DIMM-Slots, Dual Channel, max. 96GB UDIMM Non-ECC
RAM-Datenrate DDR5-5600
ECC-Unterstützung nein
M.2-Slots 1x M.2/M-Key (PCIe 4.0 x4, 2280/2242), 1x M.2/M-Key (PCIe 4.0 x4, 2242), 1x M.2/E-Key (2230, belegt mit WiFi+BT-Modul)
Grafik Intel Arc Graphics (iGPU), 8Xe/128EU/1024SP, 2.25GHz, Architektur "Xe-LPG"
Sonstige Schnittstellen 1x SATA 6Gb/s
Anschlüsse intern - USB N/A
Anschlüsse intern - sonstige N/A
Schächte 1x 2.5"
Audio Realtek ALC256
Netzwerk Intel I226-V (2.5Gb/s), Intel I226-LM (2.5Gb/s)
Anschlüsse hinten 2x USB-A 3.1 (10Gb/s), 2x HDMI 2.1, 1x RJ-45 (2.5GBase-T, Intel I226-V), 1x RJ-45 (2.5GBase-T, Intel I226-LM, vPro), 1x DC-In Hohlbuchse (Netzanschluss)
Anschlüsse vorne/seitlich 1x Thunderbolt 4 / USB4 mit DisplayPort 2.1 (40Gb/s, PD-Out), 1x USB-C 3.2 mit DisplayPort 1.4a (20Gb/s), 1x USB-A 3.1 (10Gb/s), 1x 3.5mm Klinke (Realtek ALC256)
Wireless Wi-Fi 6E (WLAN 802.11a/b/g/n/ac/ax, 2x2), Bluetooth 5.3
Angaben zur Produktsicherheit
Herstellerinformationen:
ASRock Europe BV
Bijsterhuizen 1111
Nijmegen, Niederlande, 6546 AR
info@asrock.com.tw
| Produkteigenschaft |
Wert |
| Artikelgewicht: |
1,64 kg
|
| Abmessungen
( Länge × Breite × Höhe ):
|
14,00 × 22,50 × 12,00 cm |
